Ⅰ. Introduction
ASTM A285 steel plate is a kind of pressure vessel steel plate with low and intermediate-tensile strengths which can be made by killed, semi-killed, capped, or rimmed steel practices at the producer’s option.
Ⅱ. Size of ASTM A285 Steel Plate
The maximum thickness of astm a285 steel plates is limited to a maximum thickness of 2 in. [50 mm] for all grades.
And the length and width need to be made according to both customer’s needs and the manufacturers’ production capability.
Ⅲ. Chemical Requirements
| Elements |
Grade A
|
Grade B
|
Grade C
|
| Carbon, max |
0.17
|
0.22
|
0.28
|
| Manganese, max | |||
| Heat Analysis |
0.90
|
0.90
|
0.90
|
| Product Analysis |
0.98
|
0.98
|
0.98
|
| Phosphorous, max |
0.035
|
0.035
|
0.035
|
| Sulfur, max |
0.035
|
0.035
|
0.035
|
Ⅳ. Tensile Requirements
|
Grade A
|
Grade B
|
Grade C
|
|
|
Tensile Strength
Ksi(Mpa) |
45~65
(310~450) |
50~70
(345~485) |
55~75
(380~515) |
|
Yield Strength, min
Ksi(Mpa) |
24(165)
|
27(185)
|
30(205)
|
|
Elongation in 8 in.[200mm], min, %
|
27
|
25
|
23
|
|
Elongation in 2 in.[50mm], min, %
|
30
|
28
|
27
|
Ⅴ. Heat Treatment
ASTM A285 steel plates are normally supplied in the as-rolled condition. The plates may be ordered normalized or stress relieved, or both
